| Unit of measurement | Ceileo 300 | ||
| Speed | - | 1 | 2 |
| Phases | - | 1 | |
| Minimum supply voltage | V | 230 | |
| Maximum supply voltage | V | 230 | |
| Power supply frequency | Hz | 50 | 60 |
| Weight | kg | 5.1 | |
| Ambient air temperature min | °С | 1 | |
| Ambient air temperature max | °С | 40 | |
| Ingress protection rating | - | IPX2 | |
| Trademark | Blauberg | |||||
| Model | Ceileo 300 | |||||
| Specific energy consumption (SEC) (kWh/(m²/a)) | Cold | Average | Warm | |||
| -28.7 | B | -12.3 | E | -2.9 | F | |
| Type of ventilation unit | Unidirectional | |||||
| Type of drive installed | 2-speed | |||||
| Type of heat recovery system | None | |||||
| Maximum flow rate (m³/h) | 160 | |||||
| Electric power input (W) | 44 | |||||
| Reference flow rate (m³/s) | 0.044 | |||||
| Reference pressure difference (Pa) | 50 | |||||
| Specific power input (SPI) (W/(m³/h)) | 0.156 | |||||
| Control typology | Manual control | |||||
| Maximum external leakage rates (%) | 2.7 | |||||
| Declared typology | RVU UVU | |||||
| Sound power level (dB(A)) | 57 | |||||
| The annual electricity consumption (AEC) (kWh/a) | Cold | Average | Warm | |||
| 195 | 195 | 195 | ||||
| The annual heating saved (AHS) (kWh/a) | Cold | Average | Warm | |||
| 3355 | 1715 | 776 | ||||
| ∅ D | L1 | A | B | C | E | H | h |
|---|---|---|---|---|---|---|---|
| 149 | 50 | 330 | 258 | 260 | 395 | 188 | 18 |
| Name | Photo | Description |
|---|---|---|
| Blauberg CDP-2/10 |
|
Multi-speed switch |
| Name | Photo | Description |
|---|---|---|
| Blauberg BlauFlex PVC | Flexible air ducts BlauFlex |
