/ Product catalogue / Air handling units / Pre-configured commercial AHU / Horizontal Units / KOMFORT Roto EC LE/LW / KOMFORT Roto EC LE 2000-12 S17
| Unit of measurement | KOMFORT Roto EC LE 2000-12 S17 | |
| Phases | - | 3 |
| Minimum supply voltage | V | 400 |
| Maximum supply voltage | V | 400 |
| Power supply frequency | Hz | 50/60 |
| Power of electrical reheater | W | 12000 |
| Heat recovery efficiency, max | % | 93 |
| Heat exchanger type | - | Rotary |
| Heat exchanger material | - | Aluminum |
| Weight | kg | 198 |
| Transported air temperature (max) | °С | 40 |
| Transported air temperature (min) | °С | -25 |
| Ambient air temperature min | °С | 1 |
| Ambient air temperature max | °С | 40 |
| Ingress protection rating | - | IP22 |
| Ambient air humidity max | % | 80 |
| Ingress protection rating of the drive | - | IP44 |
| B | B1 | H | L | X | Y |
|---|---|---|---|---|---|
| 875 | 630 | 1010 | 1485 | 500 | 300 |
| Name | Photo | Description |
|---|---|---|
| Blauberg VRVS 50x30 |
|
Backdraft air dampers for rectangular ducts |
| Blauberg VK 50x30 |
|
Air dampers for rectangular ducts |
| Name | Photo | Description |
|---|---|---|
| Blauberg FS2 |
|
Humidity sensor |
| Name | Photo | Description |
|---|---|---|
| Blauberg FP 800x477x47 G4 |
|
G4 panel filter |
