Blauberg KOMFORT Roto EC SE 401-E L S21

Blauberg KOMFORT Roto EC SE 401-E L S21 - Air handling units with rotary heat exchanger
New
Series: KOMFORT Roto EC S
Air handling units with rotary heat exchanger
  • Power of electrical reheater: 1200 W
  • Heat exchanger type: Sorption rotary
  • Sound-insulated casing
  • Enthalpy heat exchanger
  • Bypass: Auto
  • Reheater: Built-in
  • BMS protocol: ModBus
  • Control: Smartphone
  • Casing material: Coated steel
  • CO2 sensor: Optional
  • PM2.5 sensor: Optional
Unit of measurement KOMFORT Roto EC SE 401-E L S21
Phases - 1
Minimum supply voltage V 230
Maximum supply voltage V 230
Power supply frequency Hz 50/60
Power of electrical reheater W 1200
Heat recovery efficiency, max % 85
Heat exchanger type - Sorption rotary
Weight kg 58
Transported air temperature (max) °С 40
Transported air temperature (min) °С -25
Ambient air temperature min °С 1
Ambient air temperature max °С 40
Ambient air humidity max % 60
Ingress protection rating - IP22
Ingress protection rating of the drive - IP44
Blauberg KOMFORT Roto EC SE 401-E L S21 48 397 2016
Trademark Blauberg
Model KOMFORT Roto EC SE 401-E L S21
Specific energy consumption (SEC) (kWh/(m²/a)) Cold Average Warm
-85.7 A+ -42 A -17 E
Type of ventilation unit Bidirectional
Type of drive installed Variable speed
Type of heat recovery system Regenerative
Thermal efficiency of heat recovery (%) 84
Maximum flow rate (m³/h) 397
Electric power input (W) 193
Reference flow rate (m³/s) 0.078
Reference pressure difference (Pa) 50
Specific power input (SPI) (W/(m³/h)) 0.28
Control typology Local demand control
Maximum internal leakage rates (%) 2.7
Maximum external leakage rates (%) 2.7
Sound power level (dB(A)) 48
The annual electricity consumption (AEC) (kWh/a) Cold Average Warm
148 148 148
The annual heating saved (AHS) (kWh/a) Cold Average Warm
8938 4569 2066
Datasheet
KOMFORT Roto EC S - data sheet
1.78 Mb
Manual
KOMFORT Roto EC S - user's manual
10.46 Mb
Manual
Modbus table for connecting S21 automation to BMS - user's manual (B55-8-1EN-02)
141 Kb
Manual
S21 - user's manual (B55-8EN-05)
626 Kb
BIM/CAD-models
KOMFORT Roto EC S 281 / 401 - BIM model
1.59 Mb
BIM/CAD-models
KOMFORT Roto EC S 601 - BIM model
1.47 Mb
BIM/CAD-models
KOMFORT Roto EC S(E) 401-E L S21 - CAD model
475 Kb
KOMFORT Roto EC SE 401-E L S21 - image 1
481 Kb
Ø D H H1 L L1 W / B W1 / B1
160 588 638 513 209 598 397
